492
6. If required, release the fixing and remove the detent wheel from the selector drum.
Discard the fixing.
1. Fixing
2. Retaining plate
3. Selector drum
4. Fixing
5. Detent wheel
Gear Change Shaft Inspection
Inspect the gear change shaft assembly and spring for damage or wear, the springs for
overextension (i.e. abnormal gaps between coils). Renew the components as necessary.
