505
3. Withdraw the sprag clutch housing and remove the sprag clutch from the housing.
1. Sprag clutch housing
2. Sprag clutch assembly
Starter Drive/Sprag Clutch – Inspection
1. Check the sprag clutch bearings for overheating, wear and/or non-smooth operation.
Replace the sprag clutch if overheating, wear and/or non-smooth operation is found.
2. Examine all gears for chipped teeth and for any other damage.
3. With the sprag clutch mounted in the housing, check the sprag clutch for smooth,
free movement in one direction only (as indicated by the arrow marked on the sprag
clutch body).
Starter Drive/Sprag Clutch – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
