506
1. Locate the sprag clutch to the sprag clutch housing as shown below. Push firmly until
the lip seats in the recess provided in the housing.
1. Sprag clutch housing
2. Sprag clutch assembly
2. Fit the sprag clutch housing to the alternator rotor.
3. Make sure that the housing is squarely seated and is not on the rotor. Install new
fixings.
4. Tighten the sprag clutch housing in the sequence shown below to 16 Nm.
Tightening Sequence
