Triumph Rocket 3 GT 2021 - Page 553

525
Oil Pump Body Clearance
NOTICE
When measuring the oil pump body clearance, make sure the scavenge rotors are
fitted to their housing and the pressure rotors are fitted to their pressure housing.
1. Measure the oil pump body clearance using feeler gauges.
2. For specifications refer to Lubrication.
Pump Body Clearance
Oil Pump End Clearance
6. Remove the end plate from the pump.
7. Using a lint free cloth, wipe the exposed areas of the rotors and the machined face of
the end plate with a lint free cloth.
