Triumph Rocket 3 GT 2021 - Page 552

524
Oil Pump Rotor Tip Clearance
NOTICE
When measuring the rotor tip clearance, make sure the scavenge rotors are fitted to
their housing and the pressure rotors are fitted to their pressure housing.
1. Measure the rotor tip clearance using feeler gauges.
2. For specifications refer to Lubrication.
Rotor Tip Clearance
