Triumph Rocket 3 GT 2021 - Page 555

527
13. For specifications refer to Lubrication.
1. Rotor (outer)
2. Plastigauge
3. Gauge, in millimetres
14. If the clearance measured is within the specified tolerance, clean off all traces of
Plastigauge from the outer rotor and oil pump cover.
10. If any clearance measured is outside the service limits, renew the complete pump.
