20. Detach the brake line and its grommet from the purge valve bracket. Remove the
brake line.
21. Disconnect the front ABS sensor connector.
22. Detach the hose from the purge valve, remove the purge valve and bracket assembly.
1. Brake line
2. Grommet
3. Hose
4. Purge valve
5. Purge valve bracket
23. Disconnect the coolant temperature sensor from the main harness.
24. Disconnect the cooling fan speed controller from the main harness.
25. Remove the engine oil dipstick.
