Triumph Rocket 3 GT 2021 - Page 577

549
33. Remove the bolt, lock nut and washer securing the frame to the left hand side of the
crankcase. Discard the lock nut.
34. Remove the lock nut and washer securing the frame to the left hand side of the
cylinder head. Discard the lock nut.
1. Bolt
2. Lock nut
3. Washers
4. Frame (left hand side)
35. Remove the front cylinder head mounting bolt and washer from the right hand side.
1. Bolt
2. Washers
