Triumph Rocket 3 GT 2021 - Page 595

567
61. Attach the rear brake line to the union block at the front of the sump and tighten to
5 Nm.
1. Rear brake line
2. Union block
62. Route the brake line and the coolant expansion tank hose as noted for removal. Fit
the brake line two rear brackets and tighten the fixings to 5 Nm.
1. Fixings
2. Brake line bracket
3. Brake line
