616
Freeze Frame Data
Freeze frame data is stored at the time a DTC is recorded (confirmed) by the ECM. If
multiple DTCs are recorded, the freeze frame data which is stored will relate to the first
recorded DTC only.
By calling up freeze frame data associated with the first recorded DTC, the technician can
check the engine condition at the time the fault occurred. The data available is:
Function Examined
Report Method
DTC
Diagnostic Trouble Code (DTC) number
Fuel system status
open or closed loop operation
Calculated load
%
Coolant temperature
°C
Short term fuel trim
%
Intake manifold absolute pressure
mmHg
Engine speed
RPM
Vehicle speed
km/h
Ignition advance
degrees
Intake air temperature
°C
Throttle position
%
Oxygen sensor output Voltage
Volts
Oxygen sensor short term fuel trim
%
