650
Oxygen Sensor Heater
Fault
Code
Possible cause
Action
P0030
Oxygen sensor heater open circuit or
short to ground - bank 1 sensor 1
View and note 'freeze-frame' data if
available.
View and note 'sensor' data.
Make sure sensor connector is secure.
Disconnect engine ECM and proceed
to pinpoint test 1:
P0032
Oxygen sensor heater short circuit to
battery positive - bank 1 sensor 1
Pinpoint Tests
Test
Result
Action
1
Check cable and terminal integrity:
- Engine ECM pin A08
- EMS relay pin 5
OK
Disconnect oxygen sensors
and proceed to test 2
Faulty
Rectify fault, proceed to
test 5
2
Check cable for short circuit:
- - Engine ECM pin A08 to ground
OK
Proceed to test 3
Short
Circuit
Locate and rectify wiring
fault, proceed to test 4
Test
Result
Action
3
Check cable continuity.
- Engine ECM pin A08 to oxygen
sensor pin 4
- Engine ECM pin C22 to oxygen
sensor pin 3
OK
Proceed to test 4
Open
Circuit
Locate and rectify wiring
fault, proceed to test 4
4
Check cable for short circuit:
- - Engine ECM pin C22 to Engine
ECM pin A08
OK
Renew oxygen sensor,
proceed to test 5
Short
Circuit
Locate and rectify wiring
fault, proceed to test 5
5
Reconnect harness, clear fault code
and run engine. Check adaption status.
OK
Action complete - quit test
Fault still
present
Contact Triumph service
