Triumph Rocket 3 GT 2021 - Page 703

665
Purge Valve
Fault
Code
Possible cause
Action
P0443
Purge valve short circuit to ground or
open circuit
View and note diagnostic software
'sensor' data.
Make sure the purge valve connector
is secure.
Disconnect engine ECM and proceed
to pinpoint test 1:
P0459
Purge valve short circuit to battery
positive
Disconnect the purge valve and
proceed to pinpoint test 5:
Pinpoint Tests
Test
Result
Action
1
Check cable and terminal integrity:
- Engine ECM pin A08
- Engine ECM pin A21
- Engine ECM pin B01
- EMS relay pin 5
OK
Proceed to test 2 for P0443
Proceed to test 3 for P0459
Faulty
Rectify fault, proceed to
test 7
2
Check cable for short circuit:
P0443
- Engine ECM pin B01 to ground
Open
Circuit
Proceed to test 4
Short
Circuit
Locate and rectify wiring
fault, proceed to test 7
3
Check cable for short circuit:
P0459
- Engine ECM pin A06 to EMS relay
pin 5
OK
Proceed to test 4
Short
Circuit
Locate and rectify wiring
fault, proceed to test 7
4
Check cable continuity:
- EMS relay pin 5 to purge valve pin 2
- Engine ECM pin B01 to purge valve
pin 1
OK
Proceed to test 5
Open
Circuit
Locate and rectify wiring
fault, proceed to test 7
5
Check resistance value, reconnect
Purge valve:
- Engine ECM pin B01 to EMS relay
pin 5
22 Ohms
to 30
Ohms
Proceed to test 7
Open
Circuit
Disconnect purge valve and
proceed to test 6
Short
Circuit
Disconnect purge valve and
proceed to test 6
