Triumph Rocket 3 GT 2021 - Page 704

666
6
Check purge valve resistance,
disconnect Purge valve:
- Valve pin 1 to valve pin 2
22 Ohms
to 30
Ohms
Proceed to test 7
Faulty
Renew purge valve,
proceed to test 7
7
Reconnect harness, clear fault code
and run diagnostic software function
test to visually verify operation of
purge valve.
OK
Action complete - quit test
Fault still
present
Contact Triumph service
1. Engine ECM Connector A
2. Engine ECM Connector B
3. Secondary Air Injection Valve
4. Engine Management System Relay
