704
1. Fuse Box
2. Ignition Relay
3. Switch Housing Subharness (main harness side)
4. Switch Housing Subharness (subharness side)
5. Right Hand Switch Housing (black connector)
6. Engine ECM Connector A
7. Fuel Pump Relay
EMS Main Relay Circuit
Fault
Code
Possible cause
Action
P1685
Main relay circuit malfunction
Note that the starter motor cannot be
powered if a main relay fault exists.
Ensure the EMS main relay connector
is secure.
Proceed to pinpoint test 1:
