Triumph Rocket 3 GT 2021 - Page 741

703
Pinpoint Tests
Test
Result
Action
1
Check cable and terminal integrity:
- Engine ECM pin A11
- Right hand switch housing pin 6 (black
connector)
- Right hand switch housing pin 4 (black
connector)
OK
Proceed to test 2
Faulty
Rectify fault, proceed to
test 3
2
Check cable for short circuit:
- Engine ECM pin A11 to ground
OK
Procced to test 3
Short
Circuit
Locate and rectify wiring
fault, replace Fuse 1 and
proceed to test 5
3
Check cable continuity:
- Engine ECM pin A11 to Ignition Relay
pin 5
- Ignition Relay pin 3 to fuse box fuse 1
OK
Proceed to test 4
Open
Circuit
Locate and rectify wiring,
keyless module, or engine
stop switch fault, proceed
to test 4
4
Check fuse box fuse 1 integrity.
OK
Procced to test 5
Faulty
Replace Fuse 1 and
proceed to test 4
5
Reconnect harness, clear fault code and
run engine to verify fault cleared.
Note that the engine stop switch must be
in the RUN position and any alarm fitted
must be disarmed
OK
Action complete - quit test
Fault
still
present
Contact Triumph service
