Triumph Rocket 3 GT 2021 - Page 745

707
Pinpoint Tests
Test
Result
Action
1
Check cable and terminal integrity:
- Engine ECM pin C24
- Engine ECM pin C25
- Instrument pin 24
- Instrument pin 25
- ABS module pin 2
- ABS module pin 11
- Diagnostic connector pin 6
- Diagnostic connector pin 14
- Keyless module pin 13
- Keyless module pin 5
- Steering lock module pin 5
- Steering lock module pin 4
- Bluetooth module pin 3
*
- Bluetooth module pin 4
*
OK
Disconnect and proceed
to test 2
Faulty
Rectify fault, proceed to
test 5
2
Check cable for short circuit:
- Engine ECM pin C24 to ground
- Engine ECM pin C25 to ground
OK
Procced to test 3
Short
Circuit
Locate and rectify wiring
fault, proceed to test 5
3
Check cable for short circuit:
- Engine ECM pin C24 to Engine ECM pin
C25
OK
Proceed to test 4
Short
Circuit
Locate and rectify wiring,
fault, proceed to test 5
