708
Test
Result
Action
4
Check cable continuity:
- Engine ECM pin C24 to Instrument pin
24
- Engine ECM pin C25 to Instrument pin
25
- Engine ECM pin C24 to ABS control
module pin 11
- Engine ECM pin C25 to ABS control
module pin 2
- Engine ECM pin C24 to Diagnostic
connector pin 14
- Engine ECM pin C25 to Diagnostic
connector pin 6
- Engine ECM pin C24 to Keyless module
pin 5
- Engine ECM pin C25 to Keyless module
pin 13
- Engine ECM pin C24 to Steering lock
module pin 4
- Engine ECM pin C25 to Steering lock
module pin 5 - Engine ECM pin C24 to
Bluetooth® module pin 4
*
- Engine ECM pin C25 to Bluetooth®
module pin 3
*
OK
Procced to test 5
Open
Circuit
Locate and rectify wiring
fault, proceed to test 5
5
Reconnect harness, clear fault code and
run engine.
OK
Action complete - quit test
Fault
still
present
Contact Triumph service
*
Bluetooth is an optional accessory.
