741
1. With the aid of and assistant, lift the fuel tank over the ignition coils and position it
onto the motorcycle. Connect the fuel hose to its spigot by gently pushing inwards
until the hose engages with a click.
1. Fuel hose
2. Slide the double check latch down (towards the spigot) until the release buttons are
covered. If the latch will not slide into position, then the fuel hose is not fully home
on its spigot and must therefore be refitted correctly.
1. Locked Position
2. Unlocked Position
