742
3. Secure to the frame with its rear sleeve and fixing only. Do not fully tighten. Make
sure the fuel tank is lifted over the ignition coils.
1. Fixing
4. Raise the front of the fuel tank 100 - 150 mm.
5. Connect the electrical connector to the fuel pump.
1. Electrical connector
6. Connect the roll over valve hose to the fuel tank.
