Triumph Rocket 3 GT 2021 - Page 781

743
7. Lower the front of the fuel tank 50 - 100 mm.
8. Connect the roll over and purge valve hoses to the evaporative canister.
1. Roll over valve hose
2. Purge valve haose
3. Evaporative canister
9. Lower the front of the fuel tank and tighten the rear fixing to 8 Nm.
1. Fixing
