To release the fuel pressure gauge from the adapter, slide the outer ferrule
downwards. This will allow the gauge to spring upwards from the adapter.
To insert the gauge to the adapter, push the gauge spigot into the adapter until a click
can be heard.
6. Make sure the gauge is visible to the side of the motorcycle.
7. Using proprietary professional automotive workshop equipment approved for fuel
handling, partially refill the fuel tank with the fuel removed earlier.
8. Refit the fuel pump fuse to the fuse box.
1. Fuel pump fuse location
9. Reconnect the battery, positive (red) lead first.
10. Start the engine and observe the fuel pressure reading on the gauge.
