747
Always use the correct fuel pressure gauge adapter (adapter 'B' for Explorer
models). Use of an incorrect adapter will result in a fuel leak. A fuel leak can result in a
fire causing damage to property and injury to persons.
4. Connect the adapter hose to the fuel pump plate outlet as shown in the illustration
below.
5. Connect the adapter between the fuel pump plate outlet and fuel hose as shown in
the illustration below. Insert the gauge to the adapter also as shown in the
illustration.
1. Fuel pump connection
2. fuel rail connection
3. Fuel pump electrical connector
4. Main harness electrical connector
