• Refill the fuel tank with the fuel drained during removal, and check carefully for fuel
leaks.
• Flyscreen - Installation
• Battery - Installation
• Seat - Installation
Fuel Pressure Checking
Observe the warning advice given in the General Information section on the safe
handling of fuel and fuel containers.
A fire, causing personal injury and damage to property could result from spilled fuel or
fuel not handled or stored correctly.
Fuel pressure is checked using service tool T3880001.
T3880001 - Fuel Pressure Gauge
1. Remove the fuel tank (see Fuel Tank - Removal) and place on a suitable support,
close to the motorcycle.
2. Using service tool T3880123, carefully connect the fuel pump connection on the main
harness to the fuel tank. Connect the other end of the extension cable to the
motorcycle main harness.
3. Select the fuel pressure gauge adapter marked 'B' from service tool T3880001.
