Fuel Pump – Inspection
1. Inspect all hoses for cracks, splits, fraying and other damage. Replace as necessary.
2. Check all hose clamps for cracks and signs of distortion. Replace as necessary.
3. Check the mesh filter for damage and replace if necessary.
Fuel Pump – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
Observe the warning advice given in the General Information section on the safe
handling of fuel and fuel containers.
A fire, causing personal injury and damage to property could result from spilled fuel or
fuel not handled or stored correctly.
1. Position the fuel pump to the bracket, make sure the fuel pump base engage correctly
in the fork of the bracket.
1. Fork
2. Isolator feet
2. Align the fuel pump to the fuel pump bracket and fit the hose on to the fuel pipe.
