3. Reconnect the fuel pump electrical connector.
1. Hose clip
2. Electrical connector
4. Fit the fuel pump strap, ground cable as noted for removal, secure with a new fixing
and tighten to 4 Nm.
5. Position the baffle housing hose clip loosely over the fuel pump body.
6. Check that the baffle material within the baffle housing is positioned as noted for
removal.
7. Fit the baffle housing over the fuel pump, as noted for removal. Fit the hose clamp
and tighten to 4 Nm.
Perform the following operations:
• Fuel Pump Assembly - Installation
