771
2. Release the four fixings and detach the plenum base from the throttle bodies.
3. Disconnect the ignition master switch from the main harness.
1. Ignition master switch
2. Connector
4. Disconnect the crankcase breather pipe, the air temperature sensor electrical
connector and remove the plenum base.
1. Fixings
2. Plenum base
3. Crankcase breather pipe
4. 4. Air temperature sensor
