770
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Fuel Tank - Removal
• Left hand Side Panels - Removal
• Manifold Absolute Pressure (MAP) Sensor - Removal
• Remove the air intake runner Air Filter - Renew
1. Release the fixings and remove the plenum cover, remove and discard the plenum
seal.
Plenum Cover Release Sequence
Note that the crankcase breather pipe is attached to rear of the plenum base near the
lower right hand corner.
The air temperature sensor is also attached to the rear of the plenum base on the right
hand side.
