769
Stage 2
7. Tighten the fixings one to ten in the sequence shown to 8 Nm.
Plenum Cover Tightening Sequence
Perform the following operations:
• Fit the air intake runner Air Filter - Renew
• Left hand Side Panels - Installation
• Fuel Tank - Installation
• Battery - Installation
• Seat - Installation
Plenum - Removal (US Markets Only)
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
To Next Page
