768
1. Connect the crankcase breather pipe and the air temperature sensor electrical
connector to the plenum base.
2. Position the plenum base on to the throttle bodies.
3. Fit the four fixings and tighten to 8 Nm.
1. Fixings
2. Plenum base
3. Crankcase breather pipe
4. Air temperature sensor
4. Fit a new seal to the plenum base.
5. Fit the plenum cover to the base and tighten the plenum cover fixings in the
following two stages:
Stage 1
6. Tighten the fixings one to four in the sequence shown to 4 Nm.
