819
2. Connect the electrical connector and position the temperature sensor with the hose
routed as for removal. Fit and tighten the fixing to 3 Nm.
1. Fixing
2. Electrical connector
3. Hose
4. Temperature sensor
3. With harnesses as noted for removal, fit the fit the flyscreen mounting to the front
subframe and tighten the fixings to 5 Nm.
4. Connect the two handlebar sub harness and the twist grip position sensor connectors
to the main harness as noted for removal.
