838
7. While supporting the catalytic converter release the fixing on the right hand side and
remove the catalytic converter. Discard the lock nut.
1. Fixing
2. Lock nut
3. Catalytic converter bracket
8. Remove and discard the exhaust gasket from the header pipe.
Catalytic Converter – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
1. If removed, apply a thin smear of anti-seize compound to the threads of the oxygen
sensor, install the oxygen sensor and tighten to 25 Nm.
2. Fit the bushes and shouldered washers to the catalytic converter as noted for
removal.
3. Fit a new exhaust gasket to the header pipe.
