839
4. Position the catalytic converter clamp onto the header pipe.
5. Fit the catalytic converter to the header pipe and position to its mountings on the
motorcycle. Fit the fixing and a new lock nut to the right hand mounting. Do not fully
tighten at this stage.
1. Fixing
2. Lock nut
3. Catalytic converter bracket
6. Align the catalytic converter right hand mounting to the side stand bracket. Fit the
fixing and a new lock nut. Do not fully tighten at this stage
1. Fixing
2. Lock nut
3. Side stand bracket
