Triumph Rocket 3 GT 2021 - Page 878

840
7. From the left hand side, fit the centre fixing securing the catalytic converter to the left
hand drag link bracket. Do not fully tighten at this stage.
1. Fixing
2. Catalytic converter bracket
3. Drag link bracket
8. Fit the catalytic converter to the header pipe. Fit the clamp as noted for removal and
tighten to 11 Nm.
1. Clamp
2. Catalytic converter
3. Header pipe
