Triumph Rocket 3 GT 2021 - Page 918

880
3. Remove the fixings and the flanged sleeves securing the radiator assembly to the
frame.
1. Fixing (left hand side shown)
2. Flanged sleeve
3. Frame
4. Grommet
4. Disconnect the lower coolant hose from the engine.
5. Support the radiator assembly and disconnect the cooling fans electrical connectors.
1. Connectors
