Perform the following operations:
• Seat - Removal
• Battery - Removal
• Radiator Cowl - Removal
• Coolant Replacement - Drainage
• Coolant Expansion Tank - Removal
NOTICE
Note the positions and orientations of the grommets, flanged sleeves and washers for
installation.
1. Disconnect the horn electrical connectors, release the fixing and remove the horn.
2. Remove the fixings and the flanged sleeves securing the radiator assembly to the
lower bracket.
1. Fixing (left hand side shown)
2. Flanged sleeve
3. Grommet
4. Bracket
