Triumph Rocket 3 GT 2021 - Page 920

882
1. If removed, fit the cooling fan assembly to the radiator and tighten the fixings to 8
Nm.
1. Fixings
2. Cooling fan assembly
2. Connect the upper coolant hose and secure with its clamp orientation as noted for
removal.
3. Support the radiator assembly and connect the cooling fans electrical connectors.
1. Connectors
4. Connect the lower coolant hose to the engine.
