890
7. Pressure test the cap to it's 1.2 bar blow off pressure. If the coolant cap opens at a
lower pressure, fails to open at the correct pressure or the seal leaks, replace the cap.
8. Release the pressure from the coolant test kit using the pressure release valve.
9. Remove the coolant pressure cap from service tool T3880147.
Thermostat – Removal
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
Perform the following operations:
• Radiator - Removal
1. Release the fixings and remove the thermostat cover. Discard the gasket.
Note the position of the bypass hole in the thermostat for installation.
Note the position of the two hollow dowels for installation.
2. Remove the thermostat.
1. Fixings
2. Cover
3. Gasket
4. Thermostat
5. Bypass hole
6. Hollow dowels
