Triumph Rocket 3 GT 2021 - Page 938

900
4. Remove the direction indicator bracket pinch bolt.
1. Fixings
2. Upper yoke
3. Fixing
4. Direction indicator
5. Remove the lower yoke pinch bolt and slide the fork down through the yokes.
Discard the pinch bolt.
2. Fixings
6. As the fork is released, slide the direction indicator brackets off the fork and tie aside.
Do not allow the direction indicators to hang on the wiring harnesses.
