Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
1. Position the indicator clamp end between the upper and lower yoke.
2. Install each fork through the lower yoke, and slide the direction indicator clamp on to
the forks.
3. Position the fork through the lower yoke so that the upper surface of the top cap is
7.7 mm (+/- 0.5 mm) is above the upper surface of the upper yoke.
2. Upper yoke
1. Fit new fixings and tighten the lower yoke pinch bolts in the following two stages:
Stage 1
2. Tighten the fixings in the sequence shown to 25 Nm.
