902
Stage 2
3. Tighten the fixings in the sequence shown to 25 Nm.
Lower Yoke pinch Bolts Tightening Sequence
4. If the fork top caps have been loosened, tighten them to 35 Nm.
5. Tighten the upper yoke clamp bolts to 25 Nm.
6. Position the direction indicator as noted for removal and tighten its fixing to 3 Nm.
