918
10. Slide the switch housing off the handlebar and collect the retaining clip.
1. Left hand switch housing
2. Retaining clip
11. Remove the cable tie securing the switch housing wiring harness to the right hand
switch housing.
12. Gently pull on the wiring harness to disconnect the switch housing connectors.
13. Insert service tool T3880369 into the opening on the right hand switch housing until
a click is felt/heard.
14. Slide the switch housing towards the end of the handlebar to free it from the
retaining clip.
15. Withdraw service tool T3880369 from the switch housing.
16. Slide the switch housing off the handlebar and collect the retaining clip.
1. Right hand switch housing
2. Retaining clip
