Triumph Rocket 3 GT 2021 - Page 958

920
19. With the aid of an assistant, support the handlebar and release the fixings and
remove the clamps.
1. Fixings
2. Handlebar clamps
NOTICE
Note the position of the instruments riser and clamp on the handlebar for installation.
20. If required, release the four fixings and remove the instruments mounting and friction
rings assembly.
1. Fixings (clamp)
2. Fixings (riser)
3. Clamp
4. Riser
5. Friction ring
