922
2. Carefully fit the twist grip position sensor harness first into the handlebar as noted
for removal.
3. Carefully fit the switch housing harnesses into the handlebar as noted for removal.
1. Harness (right hand switch housing)
2. Harness (left hand switch housing)
3. Handlebar
4. Fit the friction rings to the instruments riser and clamp.
5. Fit the instruments riser and clamp to the handlebar as noted for removal. Fit the
fixings and tighten the upper fixings to 5.5 Nm. Do not tighten the lower fixings at
this stage.
