931
1. Release the two fixings and remove the headstock harness cover.
1. Fixings
2. Harness cover
NOTICE
Note the routing of the instruments harness for installation.
The instruments electrical connector cover is secured to the instruments with a fixing
and a retaining lug.
2. Release the fixing and manoeuvre the cover to release the retaining lug and remove
the cover.
1. Fixing
2. Cover
3. Retaining lug
4. Instruments harness
