Triumph Rocket 3 GT 2021 - Page 970

932
3. Disconnect the electrical connector from the instruments.
4. Release the fixing and detach the brake and clutch line connector block from the
upper yoke. Discard the fixing.
1. Fixing
2. Brake line connector
3. Clutch line connector
NOTICE
The clutch switch is secured to its housing by two fixings. The clutch switch housing is
a press fit to the clutch master cylinder.
Note the orientation of the clutch switch for installation.
