934
7. Release the fixings, remove the clamp then detach and support the master cylinder.
1. Fixings
2. Clamp
3. Master cylinder
NOTICE
Note the routing of the handlebar harnesses for installation.
8. Release the fixings and washer for the handlebar risers and remove the handlebar
assembly.
1. Fixing (left hand side shown)
2. Washer
3. Handlebar riser
4. Upper yoke
