Triumph Rocket 3 GT 2021 - Page 973

935
NOTICE
Note the positions of the compression limiters, rubber grommets and caps for
installation.
9. Remove the cap, compression limiter and rubber grommets from upper yoke.
1. Cap
2. Compression limiter
3. Rubber grommet
10. Loosen the upper yoke pinch bolts.
11. Remove the top nut and washer from the steering stem. Remove the upper yoke.
1. Upper yoke pinch
bolt
2. Top nut
