Triumph Rocket 3 GT 2021 - Page 974

936
Upper Yoke – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
1. Fit the upper yoke to the motorcycle.
2. Fit the washer and tighten the top nut to 90 Nm.
3. Tighten the upper yoke pinch bolts to 25 Nm.
1. Upper yoke pinch bolt
2. Top nut
