938
NOTICE
When fitting the front brake master cylinder, care must be taken to avoid trapping
switch housing harness between handlebar and reservoir clamp.
6. Locate the front brake master cylinder to the handlebars and fit the clamp.
7. Align the straight edge on the clamp to the alignment mark on the handlebar (as
shown in the illustration below) and tighten the fixings (upper one first) to 8 Nm.
6. Alignment mark
7. Straight edge
8. Clamp
8. Locate the clutch master cylinder to the handlebars and fit the clamp.
NOTICE
When fitting the clutch master cylinder, care must be taken to avoid trapping switch
housing harness between handlebar and reservoir clamp.
