939
9. Align the straight edge on the clamp to the alignment mark on the handlebar (as
shown in the illustration below) and tighten the fixings (upper one first) to 8 Nm.
8. Alignment mark
9. Straight edge
10. Clamp
10. Attach the clutch switch assembly to the master cylinder as noted for removal.
10. Clutch switch
11. Securing lugs
12. Location holes
